Rooftop HVAC Unit
İmbat, Rooftop HVAC units offer many advantages, such as independent air conditioning, certified performance, advanced control and automation, a factory-tested monoblock single unit, easy “plug-and-play” installation, and convenience in operation and maintenance. For better ventilation, the ability to operate with 100% fresh air is offered as a standard and optional feature on İmbat Rooftop HVAC units.
The İmbat Rooftop HVAC units, which feature a roof curb, allow for changes to the supply and return air directions up until the point of installation. The unit is then mounted on the curb and becomes ready for use.
Product Features
7-350 kW capacity range
R-410a refrigerant
R-454b refrigerant
R-32 refrigerant
Scroll compressor
Heating
Cooling
Wired remote control
Asymmetric cooling
Double-walled casing
Cooling + Heat pump
Cooling + Heat pump + Natural gas heating
EC fan
Thermodynamic heat recovery
Plug-and-play
Fully automatic
LCD screen
Automatic defrost
Smart defrost system
Electronic expansion valve
Indoor air quality
Free cooling
Easy service and maintenance
Ability to operate with 100% fresh air
Models with rotary and plate heat recovery
Variable air volume and low energy consumption with AC plug fan or EC fan models
Electronic expansion valve
Smoke detector
Filter clogging alarm
Hot water, steam, or electric heating
Natural gas heating
Automatic fresh air adjustment between 0-100%
Thermal or enthalpy free cooling (economizer)
CO2 indoor air quality control
Ability to connect to a building management system
Three-stage filtration option (G4+F7+F9)
Models with DC inverter scroll compressors
Hydrophilic/epoxy coating for evaporator and condenser surfaces
Condenser surface protection cage
Water-cooled models
Models suitable for high outdoor temperatures
Low sound level models
Flexible design and production for special projects
Thermal or Enthalpy Free Cooling (Economizer)
When the outdoor temperature and humidity are suitable, climatization is achieved with 100% fresh air without using the cooling system, which provides significant energy savings.
Indoor Air Quality
Indoor air quality is maintained through high-efficiency filters, a filter contamination alarm, and a CO2 indoor air quality sensor. The CO2 sensor, which controls return air pollution, works in tandem with the economizer to bring in the necessary amount of fresh air, resulting in energy savings.
Natural Gas Heating
Rooftop HVAC units with natural gas heating cells provide independent heating even in the coldest climates, without needing to be connected to a central heating system. Maximum efficiency is achieved with a natural gas burner that has a 17-55 mbar operating range and a heat exchanger with aluminized steel tubes.
Energy Efficiency
Offering high performance with low energy consumption, İmbat rooftop HVAC units are both environmentally friendly and economical. All our models are in energy classes A and B. This means İmbat rooftop HVAC units provide high energy savings, benefiting both the spaces they are used in and the world.
